ABOUT OF trencher MACHINE

KAZICI Trenching Machines products transmit movement process from power take-off spline to the chains through drive-line by mounting to 3-point suspension behind the tractor. With the hydraulic control system, it allows to trench a 100/150cm deep and 15/40cm wide canal.

It is a perfect solution for trenching on all types of dirt surfaces.

Trenching Machines which can be used easily by a single operator can trench between 150 and 250 meter at normal land conditions, and also makes you successful even on hard dirt surfaces.

Technical Features of the trencher machine

The trenchers are fitted with an effective hydraulic system, backfill blade, and heavy duty digging chain with digging teeth. There are many trenching options that the user can exploit. For a tractor mounted trenchers the digging chain is fully-detachable. The digging teeth are made up of tungsten carbide ideally suited for hard abrasive soils.

Self  Propelled Trencher Machine

Our brand new developed self-propelled trenching machines can progress 3 meters in a minute. Our previous trenching machines was able to be used only for self-propelled tractors. Now, we offer new self-propelled system as a standard for all new trenching machines that we product. With that technology, our machines can be used as an agricultural machine with mounting to tractors which are 60 and over horse-power. Now, with KAZICI Trenching Machines, you are able to trench with your every different brand and model tractors.



KAZICI TRENCHING MACHINES AND SOME FIELDS OF APPLICATION:

-It can be used for all interrow tillage and watering projects without damaging trees.

-It can be used for trickle irrigation and planting subsurface PE Tubes and Tube Coils.

-It can be used for underground electric lines.

-It can be used for drainage excavations at sports arenas.

-It can be used for water evacuation projects by drainage on terrains which has a high water table.

-It can be used for subsurface drainage systems to prevent ponding.

Handling these machines require skills on the part of the users, therefore it is vital that prior to using the trenching machine devices, the users receive appropriate training.

Steps to take to maintain these machines from getting damaged

Since our machines like the Trenching Machine 48C32 are mechanical items therefore overuse of these devices lead to corrosion. It is therefore very much important to maintain these items. It is natural that the device parts get damaged because of overuse. And for all such issues concerning our trenching equipments, prior to purchase the equipment, the user should seek advice from our customer service professionals.

Trencher machine, Trenching machine trencher machine About Trencher Machine Trencher Machine 300x163

Trencher machine, Trenching machine

Trenching Machine 40B38

Tractor power range: 40-80 HP.

Trench length: 180-300 mt/hour.

Trench width: 15cm.-33cm. / Trench depth: 100 cm.

Machine weight: 900 kg/1984 lbs.

Machine size: length-320cm / width-200cm / height-145cm

Tractor mounted trenchers trencher machine About Trencher Machine Tractor Mounted Trenchers 48C32 300x163

Tractor mounted trenchers

Trenching Machine 48C32

Tractor power range: 60-80 HP.

Trench length: 200-320 mt/hour.

Trench width: 20cm.-35cm. / Trench depth: 100 cm.

Machine weight: 1600 kg/3527 lbs.

Machine size: length-360cm / width-180cm / height-170cm

Self propelled trenching machines trencher machine About Trencher Machine Tractor Mounted Trenching Machines 48C40 3 300x163

Self propelled trenching machines

Trenching Machine 48C40

Tractor power range: 85 -100 HP.

Trench length: 150-250 mt/hour.

Trench width: 20cm.- 40cm. / Trench depth: 150 cm.

Machine weight: 1700 kg/3747 lbs.

Machine size: length-400cm / width-180cm / height-170cm

As it can be seen in technical data, our tractor mounted trencher machine model, 48C40, can handle most difficult land conditions with its high performance and you can progress your projects without delay. Length of canal may differ depending upon depth of excavation and soil structure. You can dig up top 150 meter average in 1 hour under difficult conditions like stony and hard soil, however digging length may go up to 250 meter in 1 hour on soft soil and pit-run terrains.
